Solar PVT Panel
Dual-effect synergy: integrating photovoltaic and solar thermal integrated technology to meet the needs of electricity, hot water and heating at the same time. The comprehensive utilization rate of solar energy reaches 60%, which is more than 50% higher than that of traditional photovoltaic equipment
Vacuum efficiency: The vacuum bonding process reduces the thermal resistance and improves the thermal energy utilization efficiency by 40%+, ensuring the efficient heat transfer
Temperature control gain: intelligent temperature control to prevent hot spots, prolong component life, and heat output up to twice the power
Intelligent Internet: built-in sensors and control system, connected to the energy platform, dynamic power adjustment, operation and maintenance costs reduced by 35%+
Meet the next-gen solution in distributed energy systems – the PVT E-Type Thermoelectric Twin Panel. It’s not just solar—it’s smart, efficient, and engineered for total energy independence.
Why it stands out:
Dual Conversion, Single Panel – Harvest both electricity and heat at once
Vacuum-Enhanced Efficiency – Better bonding, lower heat loss
Intelligent Thermal Management – Extends PV life, boosts ROI
Plug into Smart Grids – Adaptive energy output & automated controls
Designed for:
Offices with year-round hot water needs
Swimming pool heating
Zero-carbon buildings with integrated power/heating/cooling
Seasonal geothermal coupling
With over 60% total solar utilization and heat output that’s double the electric yield, it’s the ideal PVT solution for smart cities and green buildings.
Technical Parameter
type | PVT-E mould | |
outline dimension （mm） | 2279×1134×45 | |
Glass size (mm) | 2273×1128 | |
weight （kg） | 39.0 | |
electrical parameter | Maximum power (STC condition)/W | 580 |
Type of battery | Single crystal multi gate N type TOPCon | |
Number of batteries | 144（6×24）cells | |
working temperature /℃ | -40~85 | |
Maximum system voltage/V | 1500V（TUV） | |
Open circuit voltage (Voc)/V | 51.1 | |
Maximum power point voltage (Vmp)/V | 44.45 | |
Short circuit current (Isc)/A | 14.31 | |
Maximum power point current (Imp)/A | 13.05 | |
component efficiency | 22.44% | |
thermal parameter | Peak light thermal power (W) | 1180 |
dielectric capacity （L） | 1.2 | |
Medium type | Propylene glycol solution/glycol solution/water | |
Working pressure (MPa) | 0.6 | |
operate mode | Interstitial expansion | |
Interface size and quantity | G1/2 external thread, 2 | |
Heat exchanger structure | Tubular plate type | |
Heat exchanger material | red copper | |
Back panel material | Color coated panels | |
packing quantity | 28 units/tray, 616 units/40ft cabinet | |
Areas of application | Low temperature radiant heating, pool heating, cross-season heat storage, and direct heating combined with heat pumps. | |
